Hot selling PVC UPVC window and door profile panel production line

Brand Name : Kechengda

Model Number : SJSZ-65/132

Place of Origin : Qingdao,Shandong,China

MOQ : 1

Price : USD 30000~80000

Payment Terms : T/T

Supply Ability : 100

Delivery Time : 35 work days

Packaging Details : wrapping film

Screw Design : Double-screw

Screw L/D Ratio : 132:1

Condition : New

Plastic Processed : PVC, WPC

Application : Profile

Weight : 4000 KG

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Manufacturing Plant, PVC profile panel production line, Plastic profile panel extrusion machine, WPC panel decking production line, Wood plastic decking making machine, PVC WPC panel plastic panel extruder machine, Plastic panel plastic extrusion machine l

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Motor, PLC, Engine, Gearbox, Screw

Machinery Test Report : Provided

Screw Material : 38CrMoALA

Screw diameter (mm) : 65

Screw Speed (rpm) : 35rpm

Voltage : 380V/220V/440V

Dimension(L*W*H) : 20000*2000*2500MM

Power (kW) : 83

Keywords : upvc profile production line

Final product : PVC profile,window profile,WPC panel decking

Automatic Grade : Fully Automaitc

Contact Now

PVC profile production line is mainly used in PVC door & window profile,wide door plate,window plate,multi-holes pipe(four
holes,six holes,seven holes,nine holes etc.)For different sectional surface and die head,twin parallel(conical)screws extruder of different specifications can be chosen together with corresponding vacuum calibrating table,haul-off unit,cutting unit,tilter,etc.
When this line applied to Wood-Plastic profiled products for PE,PP and PVC,mainly apply to pallet,packaging plate,floor,and out door decorating materials,widely application.Wood powder and plant fiber addition volume very high (Max. Can be reached to 50-75%), equipment with high flexibility to processing material such as PP,PE,ABS,PS at onetime.
Capacity of extruder can be optionally chosen from 60-700 kg/h.The haul-off unit has applied unique lift technique of our
company.It is stable and reliable,the pulling force is large.Vacuum calibrator has applied special enlarged vortex cooling system which is good for cooling and calibrating so as to meet demand of high speed extruding.Movement speed and drawing speed of cutting machine keep synchronous.All movements are controlled by imported PLC,the design is reasonable,the operation is stable,it can conduct automatic cutting with fixed length.Powder&dust suction device can be provided.With different molds,the calibrator can choose such specifications as 4-meter,6-meter,8-meter,11-meter etc.
Machine Working Flow
Screw loader→Conical twin screw extruder→Mould→Vacuum calibration table→Cutter machine→Stacker→Electric control cabinet
Product Paramenters
Model
Max Product width(mm)
Extruder
Max. Output(kg/h)
Drive Motor Power(kw)
Haul off speed(m/s)
YF180
180
SJZ51/105 or SJZ55/110
80-120/ 120-150
18.5/ 22
0-5
YF240
240
SJZ55/110 or SJZ65/132
120-150/ 175-250
22/ 37
0-5
YF300
300
SJZ65/132
175-250
37
0-5
YF600
600
SJZ65/132 or SJZ80/156
175-250/ 250-350
37/ 55
0-3
YF900
900
SJZ80/156 or SJZ92/188
250-350/ 600-700
55/ 110
0-2.5
YF1200
1200
SJZ92/188
600-700
110
0-5

Product Tags:

panel door profile production line



UPVC door profile production line



window door profile production line


Wholesale Hot selling PVC UPVC window and door profile panel production line from china suppliers

Hot selling PVC UPVC window and door profile panel production line Images
