PVC Stone Wall Panel Plastic Extrusion Machine / Pvc Artifical Marble Production Line

Product Categories
Qingdao Kechengda Plastic Machinery Co., Ltd.
Contact Now

PVC Stone Wall Panel Plastic Extrusion Machine / Pvc Artifical Marble Production Line

Brand Name : Kechengda

Model Number : SJSZ-65/132

Place of Origin : Qingdao,Shandong,China

MOQ : 1

Price : USD 30000~80000

Payment Terms : T/T

Supply Ability : 100

Delivery Time : 35 work days

Packaging Details : wrapping film

Screw Design : Double-screw

Screw L/D Ratio : Unapplicable

Condition : New

Plastic Processed New Plastic Processed : PVC, WPC

Application : Profile, Plates

Weight : 2000 KG

Warranty : 1 Year

Key Selling Points : Energy saving

Applicable Industries : Hotels, Building Material Shops, Manufacturing Plant, Home Use, Construction works

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Motor, Pump, Gear, PLC, Other, Pressure vessel, Engine, Gearbox, Screw

Machinery Test Report : Provided

Screw Material : 38CrMoAlA

Screw diameter (mm) : 65

Screw Speed (rpm) : 34.9 rpm

Voltage : 380 V/50HZ

Dimension(L*W*H) : 20m*1.8m*2.0m

Power (kW) : 37

Capacity : 250-300kg/h

Usage : window/door/roof/office

Raw material : pvc

Final product : PVC sheet

After-sales Service Provided : Field maintenance and repair service

extruder : extruder

After Warranty Service : Field maintenance and repair service

Contact Now

PVC Stone Wall Panel Plastic Extrusion Machine/Pvc Artifical Marble Production Line

Main Components

A. Double Screw Extruder
This extruder is made by high precision special digital screw miller and the extruding property can be highly harmonized. It is firstly introduced advanced technique of producing screw with variable pitch and depth, so that the material can be more softly sheared and cut.
B. Die Head
The extrusion system applies special computer control. According to customers requirements, most reasonable structure of conical
twin screw can be made so as to achieve the best performance and material quality.

C. Three-roller calender
This part is specially designed, the pull force bearing is fully imported, and the drive life span can be prolonged.It can bear large extruding pressure.
D. Cooling Tank
The cooling system has applied special design. The heat emission area is enlarged, the cooling is rapid, and temperature control tolerance can be ± 1 degree.
E. Automatic Stacker
Made of stainless steel, more stable and easy to stack and pack.
D. Cooling Tank
The cooling system has applied special design. The heat emission area is enlarged, the cooling is rapid, and temperature control tolerance can be ± 1 degree.

Processing Flow

raw material mixing → extruder → three-roller calender → cooling tank→ haul-off → cutting machine→stacker

Applications

●resort and club
●office building and hotel
●subway

Advantages

●simple operation and high output
●high quality standard
●highly automatic and mechanized, energy saving and environmental-friendly

Technical Parameter
Machine Model
SJSZ80/156
SJSZ92/188
Suitable material
PVC
PVC
Thickness(mm)
1-8
1-8
Width(mm)
1220
1220
Total power(kw)
75
110
Output(kg/h)
400-500
600-700
