Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork

Name: Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork
Brand: Kechengda
Price: 94000 USD

Wholesale Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork from china suppliers

Brand Name : Kechengda

Place of Origin : Qingdao,Shandong,China

MOQ : 1

Price : USD 94000~150000

Payment Terms : T/T

Supply Ability : 100

Delivery Time : 35 work days

Packaging Details : wrapping film

Model Number : SJSZ-80/156

Screw Design : Single-screw

Screw L/D Ratio : 30:1

Condition : New

Plastic Processed : PP

Application : Construction template,Chinese standard 8Kg/m2X 14mm

Warranty : 1 Year

Key Selling Points : High Productivity

Applicable Industries : Manufacturing Plant

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox, Screw

Machinery Test Report : Provided

Screw Material : 38CrMoALA

Screw diameter (mm) : 90

Screw Speed (rpm) : 90rpm

Voltage : 380V or customized

Dimension(L*W*H) : 10*3.0*2.5 (m)

Power (kW) : 55

Raw material : Virgin/Recycled PP or recycled PP+Fiber Glass

Width : 1220mm

Thickness range : 12-20mm

Reuse time : 60times

line speed : 1-4m/min

After-sales Service Provided : Field installation, commissioning and training

Contact Now

PP Hollow Formwork Production Line
Raw feeding----Extrusion----Distribution----Die mold ---- Calibration device----5 roller haul-off unit----Heating oven----2 roller haul-off unit----Cutting unit----Stacker

PVC Building Formwork Production Line
Raw feeding----Extrusion----Die mold ----Calibration device---- Rubber rollers haul-off----Cutting unit----Stacker

Technology Parameters

Item	PP Hollow Formwork Production Line	PVC Building Formwork Production Line
Raw material	Recycled PP	PVC resin+wood powder
Width	915/1220mm	915/1220mm/as customer's request
Thickness	12-18mm	3-30mm
output	600kg/h	450-550kg/h
Appliacation	construction template	furniture,kitchen board and construction template or other wpc product

Plastic Modular Formwork System PP Hollow Sheet Extrusion Production Line Instead of PVC Building Formwork Images
